Upholstery Fastening System - Textile Range | Fastmount™

  • Available in

  • Use

    Mounting of soft textiles to hard surfaces
  • Applications

    Architectural, marine, aviation and recreational vehicles
  • Characteristics

    Typical applications include sun loungers, interior cushions, seat bases and backs, UV resistant
Fastmount™ Logo

Contact manufacturer

Fastmount™

Fastmount™ Logo

Contact manufacturer

Fastmount™

More from Fastmount™

Website

More about this product

The Textile Range has been specifically designed by Fastmount™ for the mounting of soft textiles to hard surfaces. The hidden system locks into place, and can only be removed by unlocking the clip, providing added security under high winds and seas. Makes cushions simple to install, remove and replace. Typical applications include sun loungers, interior cushions, seat bases and backs.

As the leader in panel mounting systems, Fastmount™ has found that bigger may not always be better, but stronger certainly is with the release of the new TC-F6H for upholstery. Building on the Textile Range’s goal to create a secure fastening of cushions combined with rapid removal, the TC-F6H is an evolution of the TC-F6, providing the same fundamental benefits, but improving on two key areas: strength and ease of fitting and removal.

Replacing previous attachment methods such as hook and loop tape, the sew-on female clip which is composed of a white housing and translucent slide-lock, makes high loading a priority while making the clip effortless to engage and disengage.

Featuring an intuitive slide-lock mechanism, the clip allows the cushion to be physically ‘locked’ into position by simply sliding the transparent slide lock into the housing. This action locks the TC-F6H onto the male clip, connecting the cushion and the deck with a mechanical connection. The slide lock is then pulled towards the edge of the cushion to release the connection and remove the cushion swiftly. This mechanical lock creates a 23kg break-out load when used with male clips TC-SM6 or TC-M6. The slide-lock device is fully replaceable even when the TC-F6H is sewn onto the cushion.

TC-F6H. Textile Clip Female Heavy Duty
Heavy-duty female clip with quick aligning, secure slide-lock function. Stitches onto upholstery during the construction process. For use with male clips TC-M6 and TC-SM6.

Benefits

  • TC-F6H sews onto cushion at the upholstery construction stage
  • Enables heavy-duty attachment of soft furnishings to painted or gel coat surfaces
  • Slide lock mechanism makes soft furnishings quick to install and easy to remove
  • High quality, secure finish
  • Heavy-duty 23kg break out load
  • No force required to release lock. Pull tab towards edge of the cushion to unlock
    and remove
  • Hidden fixing – no visible domes, screws, straps or hook and loop tape.
  • Low visibility transparent lock tab when exposed
  • Sliding lock can be replaced without unstitching saddle in the event of damage
  • No removal tool required

TC-M6. Textile Clip Male - Screw Fix
Male clip: White screw fix male for the use with #6 screw. UV resistant.

Benefits

  • Screw fixes to deck or substrate
  • Enables the attachment of soft furnishings to hard surfaces
  • Makes furnishings quick to install, and easy to remove
  • High-quality, secure finish
  • Easy alignment to replace the cushion, clip locks into place
  • Purpose-built
  • No force required to remove the furnishing – simply press one of the three buttons to disengage the lock
  • Saves removal time for staff and crew
  • Invisible fixing – no visible domes, screws, straps or hook and loop
  • 10kg break out load

TC-SM6. Textile Clip Male - VHB Tape Fix
Translucent surface mount male with Very High Bond (VHB) tape pre-attached for quick, durable install. UV resistant.

Benefits

  • VHB self-adhesive fix
  • Enables attachment of soft furnishings to painted or gel-coat surfaces
  • Makes furnishings quick to install, and easy to remove
  • High quality, secure finish
  • Easy alignment to replace the cushion, clip locks into place
  • Purpose-built
  • No force required to remove the furnishing – simply press one of the three buttons to disengage the lock
  • Saves removal time for staff and crew
  • Invisible fixing – no visible domes, screws, straps or hook and loop
  • 10kg break out load
  • VHB tape on TC-SM6 is clear in color and UV stabilized, bonds extremely well to painted, smooth flat surfaces.
  • No penetrations or screw holes in deck structure when using TC-SM6

TC-SM6S. Textile Clip Male - Sew-on
Sew-on male clip designed to be used with the TC-F6H as a fabric-to-fabric fastener for upholstery. The TC-SM6S sews on in the same way as the TC-F6H, with two parallel stitches, and can be sewn onto any type of fabric.

Benefits

  • Sew on during upholstery stage
  • Fabric to fabric fixing
  • Enables rapid removal and replacement of cushions
  • Invisible fixing
  • Simple installation with no special tools
  • Foolproof alignment
  • No force required to remove

Applications

  • Exterior cushions
  • Sundeck mattresses
  • Seating areas external & internal
  • Crew and guest areas
  • Sunbeds
  • Hotels

For more information see Fastmount™'s catalog.
