Horizon S

• Minimum Roof Slope: 3:12
• Panel Coverage: 16” coverage with 1” seam height
• Hail Resistance: UL2218, Class 4
• Fire Resistance: UL790, Class A
• Wind Uplift Test Rating: UL580, Class 90
• Maximum Panel Length: Custom cut to lengths from 5' up to 40'
• Gauge: 26

Horizon 16

• Minimum Roof Slope: 3:12
• Panel Coverage: 16” coverage with 1” seam height
• Hail Resistance: UL2218, Class 4
• Fire Resistance: UL790, Class A
• Wind Uplift Test Rating: UL580, Class 90
• Maximum Panel Length: Custom cut to lengths from 5' up to 40'

Horizon S100

• Minimum Roof Slope: 3:12
• Panel Coverage: 16” coverage with 1” seam height
• Hail Resistance: UL2218, Class 4
• Fire Resistance: UL790, Class A
• Wind Uplift Test Rating: UL580, Class 90
• Maximum Panel Length: Custom cut to lengths up to 40’

1 1/2″ SSR

• Minimum Roof Slope: 1:12
• Panel Coverage: 16” coverage with 1 1/2 ” seam height
• Hail Resistance: UL2218, Class 4
• Fire Resistance: UL790, Class A
• Wind Uplift Test Rating: UL580, Class 90
• Maximum Panel Length: Custom cut to lengths up to 40’

1 1/2″ SSR 150

• Minimum Roof Slope: 1:12
• Panel Coverage: 16” coverage with 1 1/2 ” seam height
• Hail Resistance: UL2218, Class 4
• Fire Resistance: UL790, Class A
• Wind Uplift Test Rating: UL580, Class 90
• Maximum Panel Length: Custom cut to lengths up to 40’

Ultra Loc

• Minimum Roof Slope: 3:12
