Drawer Runner - F70 | Salice

  • Available in

  • Use

    pull-out units, runners
  • Applications

    Kitchens
  • Characteristics

    Supplied in preassembled kits, easy installation, tool-free operation, fluid movement
  • Presentation / packaging

    Bright zinc-plated
Salice Logo

Contact manufacturer

Salice

Salice Logo

Contact manufacturer

Salice

More from Salice

Website Phone

More about this product

The F70 drawer runner from Salice offers a product for heavy-duty and high-capacity usage. It can be installed both with wooden and Lineabox aluminum drawers. The runner is available in two versions, Smove and Push.

Systems

The F70 runner is available in two system versions. The first system from Salice is the Smove version, which is characterized by decelerated closing. The second version is the Push version which is characterized by the integrated push opening mechanism allowing for handle-less drawers. The self-opening mechanism is activated via pressure applied on any part of the front of the drawer. The Push version can also be equipped with a synchronization system that allows the opening of drawers of any width.

F70 - Heavy Duty Drawer Runner

Design

The F70 runner is available in a full range of lengths from 350 mm to 750 mm and includes an integrated rack system. The rack system synchronizes the three sliding elements resulting in high lateral stability and a silent sliding movement. The runner is fixed to the drawer by a clipping action with pressed steel elements. The F70 also is equipped with:

  • Tool-free sideways adjustment +/- 1.5 mm, integrated into the clip
  • Tool-free depth adjustment +/- 3 mm, integrated into the clip;
    through the oval slot on the runner, it is possible to obtain a further depth adjustment of +/- 4.5 mm
  • Tool-free height adjustment + 2.5 mm, integrated into the clip;
    through the oval slot on the runner, it is possible to obtain a further height adjustment of +/- 6 mm
  • Tool-free tilt adjustment + 3 mm (optional, when the optional lever is fitted)
    Max. drawer side thickness: 16 mm

Applications

The features and distinctive elements of Salice's F70 drawer runner make it suitable to meet the needs of a variety of furniture and room settings. This includes elements in the kitchen, and bathroom, as well as living, bedroom, and office spaces.
